| Dust and splash protection | IP54 |
|---|---|
| Working range, value | 15 m |
| Working range with receiver | 15 m |
| Accuracy | Horizontal laser line: ± 0.2 mm/m ; Vertical laser lines: ± 0.3 mm/m |
| Colour of laser line | Green |
| Laser diode | Line: 500 – 540 nm, < 10 mW, Point: 630 – 650, < 1 mW |
| Operating temperature | -10 – 45 °C |
| Storage temperature | -20 – 70 °C |
| Laser class | 2 |
| Working range of laser points, max. | 5 m (bottom) |
| Self-levelling range | ± 3° |
| Levelling time | 4 s |
| Power supply | 4 x 1.5 V LR6 (AA) |
| Weight, approx. | 0.5 kg |
| Color of plumb points | Red |
| Order number | 06010657K1 |
Measuring Tools
Bosch GLL 50-15 XG + BT 150-5/8 Line Laser
Price on request
Green cross line laser with a 15 m range, ±0.2 mm/m horizontal accuracy and a red plumb point, supplied with the BT 150 tripod. Detachable rotating platform for precise line positioning.
| Range | Bosch Professional |
|---|---|
| Order number | 06010657K1 |
